BS 1377 Part 8 1990
Triaxial Saturation
Location Job Ref:
BH No.
Soil Description Sample No.
Depth
Test method  BS1377: Part 8:  1990 Clauses 5.3/5.4* Date


Consolidated-undrained/consolidated-drained*triaxial compression test
With/without*side drains     Date started     Completed
Pressure system no.       Cell no.
Required effective pressure s3 kPa     Initial diameter Do mm
Cell pressure   s3 kPa     Initial length Lo mm
Back pressure   ub kPa     Initial area Ao mm2
Pore pressure after build-up ui kPa     Initial volume Vo cm3
Excess pore pressure   (ui - ub) kPa
   Consolidation data
Date   Time Elapsed time /t Volume change   Pore pressure
      t(min)     indicator
            Reading Difference Reading Difference Dissipation
                  u (ui - u)   U
            mL mL     kPa   %












Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap


Final difference =
total consolidation volume change DVc
After consolidated
Consolidated volume Vc = Vo - DVc   cm3     Coeffiecient of volume
Volumetric strain ev =  DVc     Compressibility
  Vo     mvi = 1000ev
Consolidated length Lc = Lo(1 - 1/3 ev) mm       (ui - uc)
Consolidated area Ac = Ao(1 - 2/3 ev) mm2     mvi =     m2/MN
Value of l     Value of F       Coeffiecient of
From graph / t100   t 100 =      min Consolidation

Significant testing time tf = Ft100 min cvi = 2.1 Ac m2/year
  lt100
Significant strain : assumed failure/reading intervals* ef =
Calculated rate of axial displacement   dr = efLc         mm/min
              tf
Selected machine speed                 mm/min
*Delete as appropriate


  Operator Checked Approved

                                                                                                                                        Form 8C
