BS 1377 : Part 4 : 1990
Dry density/moisture content relationship (rammer)
Location         Job ref.
          Borehole/Pit no.
Soil description         Sample No.
          Depth     m
Test method  BS1377: Part 4:  1990: 3.3/3.4/3.5/3.6* Date
Procedure   2.5/4.5kg* hand/mechanical rammer*
  ____________layers____________blows per layer
  One litre/CBR* mould Volume of mould (V) cm3
  Single sample/separate batches*
Initial sample mass   g Particle density     Mg/m3
Retained on 20mm/37.5mm* sieve g   %
Test number
Mass of mould+base+compacted g
  specimen (m2)
Mass mould+base (m1)   g
Mass compacted specimen (m2-m1) g
Bulk density     Mg/m3
Moisture content container No.
Moisture content  (w)   %
Dry density     Mg/m3
*Delete as appropriate
      Maximum dry density     Mg/m3
  Optimum moisture content     %
dry density Mg/m3
  Moisture Content %
      Operator   Checked   Approved
  Form 4A
